Memory
Supported memory types --> DDR4-SDRAM
Number of memory slots --> 4
Type of memory slots --> DIMM
Memory channels --> Dual-channel
No ECC --> Yes
Supported memory clock speeds --> 4666,4800 MHz
Maximum internal memory --> 128 GB
Unbuffered memory --> Yes


Processor
Processor manufacturer --> Intel
Processor socket --> LGA 1200
Compatible processor --> Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel® Pentium®


Internal I/O
USB 2.0, connectors --> 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors --> 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors --> 1
Number of SATA III connectors --> 6
Front panel audio connector --> Yes
ATX Power Connector (24 pin) --> Yes
CPU Fan Connector --> Yes
TPM Connector --> Yes
Connector for RGB LED strips --> Yes


Expansion slots
PCI Express x1 (Gen 3.x) slots --> 3
PCI Express x16 Gen (3.x) slots --> 1
PCI Express x16 (Gen 4.x) Slots --> 1
Number of M.2 slots (M) --> 1


Weight and dimensions
Width --> 305 mm
Depth --> 244 mm


Storage regulators
Supported storage disk interfaces --> M.2, Serial ATA III


BIOS
BIOS Types --> UEFI AMI
ACPI version --> 6.0
System Management BIOS (SMBIOS) version --> 2.7


Package contents
Cables included --> SATA
Drivers included --> Yes


Rear Panel I/O Ports
Number of USB 2.0 ports --> 2
Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports --> 2
Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports --> 1
Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports --> 1
Ethernet LAN (RJ-45) number of ports --> 1
PS/2 mouse port --> 1
Number of HDMI ports --> 1
Number of DVI-D ports --> 1
DisplayPort version --> 1.4


Connection
Ethernet --> Yes
Ethernet interface type --> Gigabit Ethernet
LAN Controller --> Intel® I219-V
Network Connection --> Yes
Wifi --> No


Characteristics
Chipset --> Intel H570
Audio output channels --> 7.1 channels
Component for --> PC
Form factor --> ATX
Chipset Family --> Intel
Supported Windows operating system --> Windows 10 x64
